Page 4 © SAMSUNG Electronics Co., Ltd.

PREPARATION

2. Checking Parts in the Package

- Please contact your Authorised Samsung Reseller if any item above is missing or

damaged.

Handset

Dual–Jack

Modular Line

User Guide

Phone Stand

DS-5021D

NOTE
