© SAMSUNG Electronics Co., Ltd. Page 37
BASIC FEATURES
Automatic Answer Mode (Intercom Calls Only)
When another station calls you, a short signal tone will be heard and then the Digital phone automatically
answers the call.
1.
The microphone and speaker are
turned on and you can communicate
hands-free.
2.
For a private conversation, lift the handset.
3.
To end the call, replace the handset
or press either the
[End]
or
[Speaker]
button.
