© SAMSUNG Electronics Co., Ltd.
Page 31
THING
S
YOU
S
HOULD KNOW
7. Telephone Status Indicator
The status indicator turns on or off according to the telephone status.
Functions Status of LCD Indicators
Busy/Off-hook Steady red
Extension Ring Flashing red
Trunk Ring Flashing green
Recalling Flashing yellow
Message waiting Flashing red
Calling Denied Fast flashing red within 1-second interval.
