© SAMSUNG Electronics Co., Ltd.
Page III
SAFETY CONCERNS
For product safety and correct operation, the following information must be read before the
installation and operation of your DS-5021D/5014D digital phone.
Symbols
Caution
Indication of a general caution
Restriction
Indication of a prohibited action when using the product
Instruction
Indication of a required action
