1.
Press the
[Transfer] button
.
2.
Press
[1] [0] [7]
.
3.
Select the programmable button that requires
an extender by using the
[!
!!
!Volume"
""
"]
button to, scroll through programmable
buttons and then press the right Soft button,
or press the programmable button to
add an extender.
4.
When the cursor comes to the input area
on the LCD panel, dial the required extender.
5.
Save the extender by pressing the right or
left Soft button. Press the
[Transfer]
button
to finish programming.
