CONTROLLING THE G•MAJOR
• “Learning” will now no longer blink and the
G•Major has recognized which external
controller you want to control the Modifier
with and which MIDI CC value the device is
sending if any.
Of
f
Off means: No external Control of the Modifier.
Pedal
When “Pedal” is selected it is only the pedal
connected to the “External Control” jack on the
rear panel that can control the Modifier.
CC 0-127
This is where you can directly specify which CC
number the Modifier should respond to.
Step 2 - Assigning a Parameter to a Modifier
• If not already in the MOD menu press MOD
so the display shows MOD 1, 2, 3 or 4. Then
press ENTER.
Note that this is not where you select which
Modifier you are assigning, so any of the 4 will do.
You will now have a list of all the parameters
that can be controlled via a Modifier. Only
parameters in the active effect blocks are listed.
You can scroll through the parameters using
the PARAMETER wheel. In the left side of the
display you will have the parameter name and
in the right side the assigned Modifier.
• Use the PARAMETER wheel to select
parameter and the VALUE wheel to select
which of the 4 Modifiers the parameters must
be assigned to. Press ENTER and go to Step 3.
Step 3 - Setting the Modifier Response
Curve
The Modifier Response Curve determines how
the Modifier responds to e.g. the movement of
an Expression pedal. There are three
parameters to set.
MinOut
Determines the Modifier Outlevel when the
Expression pedal/Modifier Input is at minimum
position.
MidOut
Determines the Modifier Outlevel when the
Expression pedal/Modifier Input is at medium
position.
MaxOut
.
Determines the Modifier Outlevel when the
Expression pedal/Modifier Input is at maximum
position.
Assigning an Expression Pedal as a
Whammy
This example requires that you have assigned
an Expression pedal to Modifier 1 using e.g. the
Learning function as described in the previous
column.
Algorithm Parameter Assigned
Modifier
Example
• Connect your Expression pedal to either the
External Control jack on the back of the
G•Major or to the connection for expression
pedals on your MIDI pedal board.
(Please see the MIDI/UTIL section on how to
calibrate your Expression Pedal if you
haven’t calibrated yet).
• Press MOD key to access the MOD menu.
• Press ENTER.
• Select the Pitch parameter using the
PARAMETER wheel and select the MOD 1
using the EDIT wheel.
The G•Major must
be calibrated to the
Expression Pedal type you connect.
This is done in the Utility menu. Please
read the description of how to
operate the Utility menu in this manual.
Which Parameters Can Be Assigned?
The parameters you can assign to Modifiers are
located in the bottom of the Mod menu. The
parameter list will vary depending on which
algorithms are active from the various effect
blocks.
24
