FLANGER VIBRATO
33
Feedback
Range: -100 to 100
Controls the amount of Feedback/Resonance
of the short modulated Delay that causes the
Flange effect. A too high Feedback setting
(above approx. 90-95%) might introduce an
actual internal Feedback resulting in a
squealing noise that in most cases is unwanted
in flanging effects. Be aware of this when
experimenting at high volumes. Setting the
parameter to “-100” reverses the phase of the
signal that is fed back to the algorithm Input.
FB Hi Cut
Range: 19.95Hz to 20kHz
A parameter that can attenuate the high-end
frequencies of the resonance created via the
Feedback parameter.
Phase Rev
Range: Off to On
Reverses the processed Flange signal in the
right channel. This gives a very wide Flange
effects and a less defined sound.
Fla Dly - Flanger Delay
Range: 0 to 50ms
A typical Delay time to achieve the Flanging
effect is around 5ms whereas Chorus effects
occur with Delay times around 10ms. You can
however choose Delay times from
0 to 50ms.
Gold Ratio
Range: Off to On
TC Engineers found years ago that when
Speed is increased the Depth must be
decreased to achieve the same amount of
perceived Flanging effect. When Golden Ratio
is set to on this value is automatically
calculated.
Golden Ratio is a feature inherited from the
classic TC 2290 processor.
Mix
Range: 0 to 100%
Sets the relationship between the dry signal
and the applied effect in this block.
Out level
Range: -100 to 0dB
Sets the overall Output level of this block.
Vibrato - CHO/FLA Block
A Vibrato effect modulates the incoming pitch.
The result is similar to the vibrato technique
used by vocalists. As opposed to a Chorus
effect no direct signal is combined with this
pitch modulation.
Speed
Range: 0.050Hz to 19.95Hz
The speed of the Vibrato, also known as Rate.
The speed of this effect block is either
defined by this parameter or by the
Tempo parameter which sets the speed
according to the globally tapped tempo.
This Speed parameter is only
active/valid if the Tempo parameter is
set to “Ignored”.
Depth
Range: 0 to 100%
The amount of Pitch modulation applied.
Tempo
Range: 1/32T to 1 Bar or Ignored
The Tempo parameter sets the relationship to
the global Tempo.
When set to anything else than Ignored
the tempo defined by the Speed
parameter is ignored.
Hi Cut
Range: 19.95Hz to 20kHz
Determines the frequency above which the Hi
Cut filter will attenuate the high-end frequencies
of the generated effect. Hi Cut filters can be
used to give a less dominant effect even at high
mix levels.
Out level
Range: -100 to 0dB
Sets the overall Output level of this block.
Speed
Depth
