SIGNAL FLOW
9
ANALOG
INPUTS
[balanced]
ANALOG IN
LEVEL
DIGITAL IN
GAIN
MIX
ANALOG
OUTPUTS
[balanced]
A/D
Left
Left
Right
Right
Digital/Analog
Input Selector
Digital Output
[S/PDIF]
Digital Input
[S/PDIF]
G-Sharp
Signal
Processing
Engine 1&
Engine 2
D/A
Input PPM
