Tc Electronic G-SHARP [28/31] Appendix

APPENDIX - MIDI IMPLEMENTATION CHART

DUAL ENGINE PROCESSOR G-Sharp - MAY 2006

Function Transmitted Recognized Remarks

Basic Channel Default 1 1

Changed 1-16 OMNI-1-16

Mode Default

Messages X X

Altered

Note Number XX

True Voice X X

Velocity Note ON X X

Note OFF X X

After Touch Key’s X X

Channel X X

Pitch Bend XX

Control Change OO

Prog Change OO

SysEx OO

Common Song Pos X X

Song Sel X X

Tune

System real time Clock X O

Commands X X

Aux Messages Local ON/OFF X X

All Notes OFF X X

Active Sense X X

Reset X X

O:YES Mode 1: OMNI ON, POLY Mode 2: OMNI ON, MONO

X:NO Mode 3: OMNI OFF, POLY Mode 4: OMNI OFF, MONO

See CC list on page 27

for details.

All Controllers are

Single Byte type scaled

to parameter range.

MIDI TimeClock can be

used to set Delay tempo.
