![Konica Minolta EP2080 [134/148] Specifications](/views2/1122114/page134/bg86.png)
Type Desk Top Copier
Platen Type Stationary
Photoconductor OPC
Copying System Electrostatic Dry Powdered Image Transfer to Plain Paper
Developing System Micro-Toning System
Fusing System Lamp-Heated Roller
Types of Original Sheets, Books, and other three-dimensional objects
Maximum Original Size : A3 Lengthwise
Maximum Original Weight : 3kg.
Kinds of Paper Plain paper ( 60g/m
2
to 90g/m
2
)
Recycled paper
Special paper (Multi Bypass Tray only)
Thick paper ( 90g/m
2
to 157g/m
2
), Transparencies, Translucent paper
Copy Paper Size
First Drawer
A3L, B4L, A4L, A4C, A5L,
10"
✕
8"C, LetterC, LetterL, 11"
✕
14"L, 11"
✕
17"L, 8"
✕
13"L
210mm
✕
280mmL, 216mm
✕
297mmL, 297mm
✕
216mmC, 216mm
✕
320mmL,
220mm
✕
280mmL, 297mm
✕
430mmL, 210mm
✕
330mmL
2nd Drawer
A3L, B4L, A4L, A4C, B5L, B5C, A5L,
LetterL, LetterC, 11"
✕
14"L, 11"
✕
17"L,
Multi Bypass Tray
Crosswise : 100mm to 297mm
Lengthwise : 140mm to 432mm
Paper Feeding System First Drawer : 500 sheets
2nd Drawer : 500 sheets
Multi Bypass Tray : 50 sheets ( 80g/m
2
)
: 20 sheets ( Recycled paper or Special Paper )
Warm-up Time 30 seconds or less
First Copy A4C = 6.0 seconds or less
(in Full Size Mode using First Copier Drawer)
Copy Speed
(Approx.
copies/minute)
Full size (×1.000)
A3L : 17 B4L : 19 A4L : 22 A4C : 28
Magnification Ratios Fixed ratios
Full size: 1:1 ±0.005
Reduction ratios: ×0.500, ×0.707, ×0.816
Enlargement ratios: ×1.154, ×1.414, ×2.000
Zoom ratios: From ×0.500 to ×2.000 in ×0.001 increments
Multiple Copies Up to 999 copies (count-down system)
Exposure Control Auto Exposure Mode, Manual Exposure Mode and Photo Mode
Lost Image 1-sided copy in the full size mode
Leading edge: 3 mm
Trailing edge: 3 mm
Front edge : 1 mm
Power Requirements AC 110V, 115V, 120V, 127V, 200V-240V; 50/60Hz
Power Consumption 1.5 kW (Max.)
Dimensions Width
Depth
Height
:
:
:
650mm (Excluding Copy Tray)
684mm
513mm (Including Original Cover)
Weight 69.5 kg (Excluding Copy Tray, Starter, Toner, Copy Paper)
1. Specifications
Copier EP2080
Chapter 7
Miscellaneous
132
