Document Feeding
System
Standard Mode : 1-sided original, 2-sided original, 2-in-1, Single Feeding
Mixed Original Detection Mode:
1-sided Mixed Original Detection
2-sided Mixed Original Detection
Lightweight Original Mode
Kinds of Original Plain paper
Original Weight 1-sided original Mode, 2-in-1 Mode : 50g/m
2
to 110g/m
2
2-sided original Mode : 60g/m
2
to 90g/m
2.
Single Feeding Mode : 35g/m
2
to 200g/m
2.
Lightweight Original Mode : 40g/m
2
to 110g/m
2
Original Size 1-sided/2-sided original Mode: A3L, B4L, A4L, A4C, A5L, 210mm×330mm
2-in-1 Mode : A4C
Capacity of Document
Feed Tray
A4 or Smaller : 50 sheets (80g/m
2
)
A3, B4 : 30 sheets (80g/m
2
)
Copy Productivity 100%
First Copy with ADF A4C = 11 seconds or less
Power Source DC24V supplied from copier
Power Consumption 48W or less
Dimensions Width: 610mm Depth: 505mm Height: 125mm
Weight 14.5 kg
Duplexing Document Feeder AFR-12
Automatic Document Feeder AF-5
Document Feeding
System
Standard Mode : 1-sided original, 2-in-1, Single Feeding
Mixed Original Detection Mode: 1-sided Mixed Original Detection
Lightweight Original Mode
Kinds of Original Plain paper
Original Weight 1-sided original Mode, 2-in-1 Mode : 50g/m
2
to 110g/m
2
Mixed original Detection Mode : 60g/m
2
to 90g/m
2
Single Feeding Mode : 35g/m
2
to 200g/m
2
Lightweight Original Mode : 40g/m
2
to 110g/m
2
Original Size 1-sided original Mode: A3L, B4L, A4L, A4C, A5L, 210mm×330mm
2-in-1 Mode : A4C
Capacity of Document
Feed Tray
A4 or Smaller : 50 sheets (80g/m
2
)
A3, B4 : 30 sheets (80g/m
2
)
Copy Productivity 100%
First Copy with ADF A4C = 11 seconds or less
Power Source DC24V supplied from copier
Power Consumption 48W or less
Dimensions Width: 587mm Depth: 505mm Height: 125mm
Weight 13.0 kg
Chapter 7
Miscellaneous
1. Specifications
