English | 13
Bosch Power Tools 2 609 140 669 | (29.7.11)
f Use only original Bosch batteries with the voltage list-
ed on the nameplate of your power tool. When using oth-
er batteries, e. g. imitations, reconditioned batteries or
other brands, there is danger of injury as well as property
damage through exploding batteries.
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
While reading the operating instructions, unfold the graphics
page for the machine and leave it open.
Intended Use
The machine is intended for driving in and loosening screws
as well as for drilling in wood, metal, ceramic and plastic.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Screwdriver bit*
2 Tool holder
3 Locking sleeve
4 Torque presetting ring
5 Gear selector
6 Battery unlocking button*
7 Battery*
8 Rotational direction switch
9 On/Off switch
10 “PowerLight”
11 Handle (insulated gripping surface)
12 Drill bit with hexagon shank*
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted sound pressure level of the product
is 71 dB(A). Uncertainty K=3 dB.
The noise level when working can exceed 80 dB(A).
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745:
Drilling into metal: a
h
<2.5m/s
2
, K =1.5 m/s
2
,
Screwdriving: a
h
<2.5m/s
2
, K =1.5 m/s
2
.
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.
Technical Data
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2004/108/EC,
2006/42/EC.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
15.07.2011
Cordless Screwdriver GSR 10,8-LI
Professional
Article number
3 601 J92 9..
Rated voltage
V= 10.8
No-load speed
–1st gear
– 2nd gear
min
-1
min
-1
0–350
0–1300
Max. torque for hard/soft screw-
driving application according to
ISO 5393
Nm 30/13
Max. drilling dia.
–Steel
– Wood
mm
mm
10
19
Max. screw dia.
mm 7
Weight according to
EPTA-Procedure 01/2003 kg 0.8
Technical data determined with battery from delivery scope.
Please observe the article number on the type plate of your machine.
The trade names of the individual machines may vary.
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
OBJ_BUCH-1010-002.book Page 13 Friday, July 29, 2011 9:09 AM
