Bosch GSR 10,8-LI [14/145] Assembly

14 | English

2 609 140 669 | (29.7.11) Bosch Power Tools

Assembly

Battery Charging (see figure A)

f Use only the battery chargers listed on the accessories

page. Only these battery chargers are matched to the lith-

ium ion battery of your power tool.

Note: The battery is supplied partially charged. To ensure full

capacity of the battery, completely charge the battery in the

battery charger before using your power tool for the first time.

The lithium-ion battery can be charged at any time without re-

ducing its service life. Interrupting the charging procedure

does not damage the battery.

The lithium-ion battery is protected against deep discharging

by the “Electronic Cell Protection (ECP)”. When the battery is

empty, the machine is switched off by means of a protective

circuit: The inserted tool no longer rotates.

Do not continue to press the On/Off

switch after the machine has been au-

tomatically switched off. The battery can be damaged.

To remove the battery 7 press the unlocking buttons 6 and

pull out the battery downwards. Do not exert any force.

The battery is equipped with a NTC temperature control

which allows charging only within a temperature range of be-

tween 0 °C and 45 °C. A long battery service life is achieved

in this manner.

Observe the notes for disposal.

Changing the Tool (see figure B)

f Before any work on the machine itself (e. g. mainte-

nance, tool change, etc.) as well as during transport

and storage, remove the battery from the power tool.

There is danger of injury when unintentionally actuating

the On/Off switch.

Inserting

Pull the locking sleeve 3 toward the front and then push the in-

sert tool to the stop into the tool holder 2. The insert tool is au-

tomatically locked.

Removing

Pull the locking sleeve 3 forward and remove the insert tool.

Dust/Chip Extraction

f Dusts from materials such as lead-containing coatings,

some wood types, minerals and metal can be harmful to

one’s health. Touching or breathing-in the dusts can cause

allergic reactions and/or lead to respiratory infections of

the user or bystanders.

Certain dusts, such as oak or beech dust, are considered

as carcinogenic, especially in connection with wood-treat-

ment additives (chromate, wood preservative). Materials

containing asbestos may only be worked by specialists.

– Provide for good ventilation of the working place.

– It is recommended to wear a P2 filter-class respirator.

Observe the relevant regulations in your country for the

materials to be worked.

f Prevent dust accumulation at the workplace. Dusts can

easily ignite.

Operation

Starting Operation

Inserting the Battery

f Use only original Bosch lithium ion batteries with the

voltage listed on the nameplate of your power tool. Us-

ing other batteries can lead to injuries and pose a fire haz-

ard.

Note: Use of batteries not suitable for the machine can lead to

malfunctions of or cause damage to the power tool.

Set the rotational direction switch 8 to the centre position in

order to avoid unintentional starting. Insert the charged bat-

tery 7 into the handle so that it can be felt to engage and faces

flush against the handle.

Reversing the Rotational Direction (see figure C)

The rotational direction switch 8 is used to reverse the rota-

tional direction of the machine. However, this is not possible

with the On/Off switch 9 actuated.

Right Rotation: For drilling and driving in screws, push the

rotational direction switch 8 left to the stop.

Left Rotation: For loosening and unscrewing screws and

nuts, press the rotational direction switch 8 through to the

right stop.

Setting the Torque

With the torque presetting ring 4 the required torque setting

can be preselected in 20 steps. With the correct setting, the

insert tool is stopped as soon as the screw is screwed flush in-

to the material or when the adjusted torque is reached. The

safety clutch is deactivated in the “ ” position, e. g. for

drilling.

Select a higher setting or switch to the “ ” symbol when un-

screwing screws.

Gear Selection, Mechanical

f Actuate the gear selector 5 only when the machine is at

a standstill.

Two speed ranges can be preselected with the gear selector

Gear I:

Low speed range; for screwdriving or working with large drill-

ing diameter.

Gear II:

High speed range; for working with small drilling diameter.

If the gear selector 5 cannot be pushed through to the stop,

lightly turn the tool holder 2 with the insert tool.

Switching On and Off

To start the machine, press the On/Off switch 9 and keep it

pressed.

The power light 10 lights up when the On/Off switch 9 is

slightly or completely pressed, and allows the work area to be

illuminated when lighting conditions are insufficient.

To switch off the machine, release the On/Off switch 9.

WARNING
