Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Weight Stack Frame 1 35 Counter Poise Block 1

2 Upright Frame 1 37 Aluminous Cap Φ50*Φ10.5*8 2

3 Upper Cross Link Weldment 1 38 Plug RT50*100 3

5 Seat Frame 1 39 Seat Pad 1

6 Cam Frame 1 40 Φ25 Aluminium Grip Cap 2

7 Swivel Frame 1 41 Φ25 Aluminium Grip Ring 2

8 Plate 1 42 Rubber Plug 4

9 Shoulder Pad 2 43 Gas Spring 1

12 Grip Φ30*Φ22*270 2 45 Aluminous Cap Φ60*Φ10.5*10 1

13 Cable 1 46 Button Φ8*Φ20*23 10

15 Main Bracket 1 50 Coppery Spacer 2

16 Foot Tube 1 53 Location Ring Φ38*Φ25.6*R27*8 1

17 Guide Rod Φ19*1177 2 54 Locking Ring Φ38*Φ25.6*8 1

18 Selector Pin W/Coil 1 55 Screw M5*12 9

19 Top Plate 1 56 Rivet Nut M5 5

20 Lower Cross Link Weldment 1 58 Hex Head Bolt M10*135 2

21 Front Shroud 1 59 Hex Head Bolt M10*80 4

22 Weight Rubber Bumper 2 60 Hex Head Bolt M10*100 2

23 4.5" Pulley 2 61 Flat Head Cap Screw M10*25 2

29 Adj. Foot Plate 5 62 Hex Head Bolt M10*50 1

30 Flange 2 63 Hex Head Bolt M8*35 6

32 Bearing Φ50.8*Φ25.4*15.9 2 64 Hex Head Bolt M10*75 3

33 Main Shaft Φ25*235.7 1 65 Hex Head Bolt M10*25 4

34 Bumper Φ32*Φ25.4*40 1 66 Hex Head Bolt M12*35 4
