Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

67 Flat Head Cap Screw M10*30 5 100 Rivet Nut M8 2

68 Hex Head Bolt M10*30 6 104 Weight Plate 5LBS 2

69 Socket Head Cap Screw M4*15 1 105 Weight Plate 10LBS 3

70 Flat Washer Φ13*Φ24*1.5 11 106 Weight Plate 15LBS 10

71 Flat Washer Φ11*Φ20*2 42 107 Baffle Plate 1

73 Flat Washer Φ9*Φ22*1.6 8 108 Hex Head Bolt M8*15 2

74 Nylon Lock Nut M12 4 109 Flat Washer Φ9*Φ16*1.6 2

75 Nylon Lock Nut M10 17 110 Hex Head Bolt M10*55 3

76 Nylon Lock Nut M8 1 111 Shroud Clip 12

77 Socket Set Screw 10-32*3.2 4 112 Plastic Cover 1

78 Hex Key S=3 1 113 4.5" Pulley for Sensor 1

79 Hex Key S=6 1 114 Plate for Sensor 1

81 Hex Key 3/32" 1 115 Philips Screw M3*8 4

82 Wrench Φ6*117 1 116 Sensor 2

83 Lube 1 117 Console PCB 1

85 Socket Set Screw M8*8 4 118 Cover for Magnetic Iron 1

86 Hex Key S=4 1 119 Magnetic Iron 2

87 Nut 2 120 Screw ST2.9*9.5 2

89 Back Pad 1 121 Top Front Shroud 1

90 Spring Washer Φ8 2 122 Support 1

91 Hex Head Bolt M8*30 2 123 Top Cover 1

93 Weight Stack Space 300 2 124 Left Plug 1

98 Rear Shroud 1 125 Right Plug 1

99 Rubber Plug Φ29*Φ19*10 2 126 Hex Head Bolt M12*65 3
