Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

1 Weight Stack Frame 1 31 Bottom Side Cover 1

2 Bottom Cross Brace 1 32 Side Cover 1

3 Main Frame 1 34 4.5" Pulley 3

4 Seat Pad Support 1 35 Shroud 1

5 Hand Bracket 1 36 Plug RT50*100 1

6 Arm Bracket 1 37 Guide Rod Φ19*1177 2

7 Cam Wheel Brackets 1 38 Top Rear Shroud 1

8 Top Cross Brace 1 39 Top Front Shroud 1

9 Main Bracket 1 40 Plastic Block 11

10 Adj. Handle 1 41 Bearing Φ50.8*Φ25.4*15.9 4

11 Pin 1 42 Flange 2

12 Main Shaft Φ25.4*335.4 1 43 Plug Φ95.4*61 2

13 L Bracket 3 44 Yellow Grip 1

14 Scaleboard 1 45 Aluminium Grip Cap 2

15 Adjustable Support 1 46 Aluminium Grip Ring 2

16 Aluminium Cap Φ50*Φ10.5*8 2 47 Bumper Φ32*Φ25.4*40 1

17 Underlaying Flat Steel 1 48 Seat Pad 1

18 Press Cable 1 49 Arm Pad 1

19 Top Plate 1 50 Plastic Tube Guide 2

20 Counter Poise Block 1 51 Spring 1

21 Rubber Plug Φ29*Φ19*10 2 52 Arc Bracket 1

24 Selector Pin W/Coil 1 53 Big Aluminous Cap Φ60*Φ10.5*10 1

25 Front Support 1 54 Bushing 2

26 Button Φ8*Φ20*23 19 55 Plastic Washer Φ13*3 4

27 Weight Rubber Bumper 2 56 Plastic Cover Φ21*5.7 4

28 Adjustable Foot plate 4 57 Little Bumper Φ17*10.5 2

29 Grip Φ22*Φ30*355 2 58 Bushing Φ16*8 2

30 Top Side Cover 1 59 Plate 2
