─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

60 Top Rear Shroud-A 1 91 Flat Washer Φ9*Φ16*1.6 6

61 Short Shroud Retainer Plate 2 92 Flat Washer Φ5.5*Φ12*1 4

62 Rear Support 1 93 Nylon lock Nut M5 2

63 Connect Button Φ18*12 4 94 Nylon lock Nut M8 4

65 Hex Head Bolt M12*35 4 95 Nylon lock Nut M10 12

66 Self-Tapping Screw ST4.2*10 4 96 Nylon lock Nut M12 7

67 Hex Head Bolt M10*135 2 97 Socket Set Screw10-32*3.2 4

68 Hex Head Bolt M10*130 2 98 Hex Key s=3 1

69 Hex Head Bolt M10*100 2 99 Hex Key s=4 1

70 Hex Head Bolt M10*80 2 100 Hex Key s=5 1

71 Hex Head Bolt M10*50 4 101 Hex Key s=6 1

72 Hex Head Bolt M10*35 2 102 Flat Washer Φ9*Φ22*1.6 2

73 Hex Head Bolt M10*30 6 103 Hex Key s=3/32" 1

74 Hex Head Bolt M10*25 2 104 Wrench 1

75 Flat Head Cap Screw M10*30 5 105 Lube 1

76 Hex Head Bolt M10*20 2 106 Location ring 1

77 Socket Head Cap Screw M8*60 1 107 Locking ring 1

78 Button Head Cap Screw M8*55 1 109 Socket Set Screw M8*8 4

79 Socket Head Cap Screw M8*30 1 110 Nut 2

80 Socket Head Cap Screw M8*20 2 111 Shroud Retainer Plate 4

81 Button Head Cap Screw M6*12 2 113 Rear Shroud 1

82 Hex Nut M6 2 114 Front Shroud 1

83 Socket Head Cap Screw M5*25 2 115 Plug 48*22.7*R48 2

84 Flat Philips Screw M5*16 18 116 Hex Head Bolt M8*30 2

85 Socket Head Cap Screw M4*15 1 117 Spring Washer Φ8 2

86 Adjustable Support Sleeve 1 118 Button Φ8.1*7 10

87 Weight Stack Space 2 119 Flat Philips Screw M5*25 2

89 Flat Washer Φ13*Φ24*1.5 11 120 Rivet Nut M8 2

90 Flat Washer Φ11*Φ20*2 36
