18
19
Camera number panel
The camera number panel shows all camera-related
information, such as registration status, camera title
and recording status.
Camera number:
(Character color)
White: Camera is registered.
Gray: Camera is not registered.
(Background color)
Light blue: Image display area is displaying
images
Gray: Recording not possible or camera not
registered
Camera title: Shows the first 8 characters of the pre-
viously input camera title.
(Character color)
Same as camera number
(Background color)
Red: In the alarm state
Gray: Camera is not registered.
1-screen display (control screen only)
To display live images on a 1-screen, take the following procedures.
Displaying images on a 1-screen
Step 1
Click the camera number panel of the desired image
from the camera.
→ The background color of the selected camera
number will turn aqua blue, and live images will be
displayed.
Displaying images on a multiscreen
Step 1
Click the 1-screen button for the screen pattern.
→ The image display area will be displayed on a
1-screen.
Step 2
→ The background color of the selected camera
number will turn aqua blue, and live images will be
displayed.
Note:
• Anotherwaytodisplayimagesona1-screenisto
double-click the camera number panel of the
camera to be selected in the image display area.
• Double-clickingthecameranumberpanelwhile
displaying images is also possible to display an
image on a 1-screen.
• Inthemultiscreendisplayarea,double-clicking
the camera selection frame is also possible to dis-
play an image on a 1-screen.
• Theaudioofthecamerawhoseimagesarebeing
displayed will be output.
• Dependingontheimagesizedisplayed,theaudio
may be delayed.
• Each click of the mute button toggles between
mute and mute cancel.
Recording indicator: Lights red when recording is
being performed. Display of [
] indicates a
connection error.
Screen pattern buttons
The 1-screen/4-screen/16-screen buttons are dis-
played.
Digital zoom button
When displaying images on a 1-screen or 4-screen,
the images can be enlarged/reduced (☞ page 23).
Mute button
Each click of this button toggles between mute and
mute cancel of the camera audio.
