Display images from cameras on a multiscreen (control screen)

Live images from cameras can be displayed on a multiscreen (4-screen, 16-screen).

Step 1

Click the 4-screen or 16-screen button.

 • 4-Screen button

Each click of a button switches to the next 4

screens in the sequence: camera 1 to 4 →

camera 5 to 8 → camera 9 to 12 → camera 13 to

16.

 • 16-Screen button

The images of camera 1 to 16 will be displayed.

→ Live images from cameras will be displayed on a

multiscreen.

Note:

 • Afterhavingswitchedfrommultiscreento

1-screen display, double-clicking the image dis-

play area will display the multiscreen displayed

before switching screens.

 • Itisalsopossibletoswitchtheimagesdisplayed

on the 4-screen by clicking the camera number

panel with the 4-screen displayed. (When the

panel of camera 5 is clicked with the 1- to

4-screen displayed, the images of camera 5 to 8

will be displayed)

 • Theaudiooftheselectedcamerawillbeoutput.

 • Audiooutputmaybedelayeddependingonthe

size of the displayed image.
