Display the images recorded on the recorder’s hard disk on the main monitor.

Playback operation can be made while recording. Playback of images can be controlled from the operation dis-

play area.

Note:

 • Whenplayingrecordedimagesona1-screen,audiorecordedtogetherwiththeseimageswillbeoutput.

 • Whendisplayingrecordedimagesona4-screen,audiofromthecameratobedisplayedonascreenwillbe

heard.

 • Noaudiowillbeoutputwhenplayingbackinfastforward/fastreverse.

 • Thecameraimagecanbechangedbyclickingthecameranumber(1to16)duringplayback.

 • TheMultiscreenselectbutton,digital zoom button, Mute button and OSD button remain effective during

playback. Refer to "Monitor live images" (☞ page 18) for further information.

 • WhendisplayingimagesrecordedatSVXGAresolution(1280×960)andaframerateof15or30ipsona

4-screen, the images will be played back with the selected refresh interval.

 • Differentvaluesselectedforresolutionandframeratewillcausethedatasizeoftheplaybackimagesonthe

4-screen to differ considerably, which may result in non-synchronized playback. In this case, pause and

then restart playback (☞ page 26).

Playback operation panel

In playback mode, operation buttons are displayed on the playback operation panel. In addition to the opera-

tion buttons, the playback operation panel displays the playback status.

Normal status (during display of live images)

Play recorded images

Image data

Main monitor

HDD

Recorder

Image playback status Playback pause status
