Use digital zoom (control screen only)
Images on the 1-screen and 4-screen can be digitally zoomed. It is also possible to move the zoomed area
within the displayed image.
Note:
• Digitalzoomisnotavailableonthewideviewscreenandonthe9-screens/16-screens.
• Tousethisfunctiononthe4-screen,dosoafterfirstselectingthedesiredcameraimage.Toselectacam-
era, click the camera number panel or the camera image. Once a camera has been selected, the selection
frame will be displayed around the camera image.
Step 1
Confirm that the image display area is displayed on
the 1-screen or 4-screen.
(when displaying on the 4-screen, select the camera
whose image is to be zoomed)
Step 2
Click the digital zoom buttons [×2] [×4] [×8].
The displayed image will be enlarged x2/x4/x8
centering on the center point of the screen.
Note:
• Clickingapointinthezoomedimagemakesthe
clicked point the center of the image.
Step 3
Click the digital zoom button [x1] to cancel the digital
zooming.
Note:
• Digitalzoomisautomaticallycanceledbyother
operations such as selecting another camera or
changing the screen pattern.
• If"Enable camera control with mouse" on the
camera control panel ( page 46) is not checked,
the digital zoom factor can also be changed by
placing the cursor on the image in the image dis-
play area and turning the mouse wheel. In this
case, the point where the mouse cursor is posi-
tioned will become the zoom center.
