32
33
Step 1
Display the images from the camera to search on a
1-screen. ( Page 19)
Step 2
Click the [Search] button on the playback operation
panel. ( Page 25)
The VMD search panel is displayed.
Step 3
Designate the time range to search.
Set the year, month, day and time of the start and end
point by clicking the respective [D] / [C] buttons.
Step 4
Click the [Search] button.
This will run a VMD search within the designated
search range and display a list of results. Switch
between list pages by clicking the [Prev page]/
[Next page] buttons.
Search and play recorded images triggered by motion
detection (VMD search)
Search images recorded with a camera supporting the VMD search function by the date motion was detected
and play them. Click a time and date on the result list to play corresponding recorded images.
Important:
• Toperformthemotiondetectionsearch,itisnecessarytoconfigurethesettingsoftheconnectedcameras
that support the motion detection search function in advance. Refer to the "readme.txt" on the provided
CD-ROM about the supported camera. Refer to the operating instructions of the camera in use for further
information.
Note:
• TheVMDsearchfunctionsearchestheentire
camera image by default. To designate a search
area, click the [Setup] button next to [Detection
area / Mask duration] on the "VMD search setup"
panel. ( Page 33)
• Itmaytakesometimeuntilthesearchresultsare
displayed.
Step 5
Select the line with the desired list, and click the play
button on the playback operation panel. ( Page 25)
Playback will start from the time and date select-
ed.
Note:
• Playbackcanalsobestartedbydouble-clicking
the desired time and date line.
