70
71
Step 3
Set up a VMD area. Drag the mouse on the screen.
A frame will be displayed, and the area within the
frame will be set as VMD search area.
Note:
• Todeletethecreatedmotiondetectionarea,click
the [Delete area] button.
Step 4
Click the [OK] button.
The VMD search will start. The search result will
be displayed in the list display area. ( Page 69) It
may sometimes take time to complete the search.
Important:
• IntheresultlistoftheVMDsearch,theaudioicon
will not be displayed in the "Audio" column even if
audio is attached to the recorded images.
Step 1
Click the [Control] button on the top page ( page
58) of the operation window, and click the [VMD] but-
ton in the [Search] box.
The "VMD search" window will be displayed.
Display of live images and display of playback
images will be paused.
Step 2
Specify the search conditions (filters).
[Camera]
Select the camera for VMD search.
[Date & time range]
Select a time range by designating a start and end
time and date. The designated time range will be
searched.
[Mask duration]
Select the time span to be searched.
Search for recorded images from images recorded triggered by the VMD function of cameras by designating a
time range. Click a time and date on the result list to play corresponding recorded images.
Important:
• ToperformtheVMD search, it is necessary to configure the settings of the connected cameras that support
the motion detection function in advance. Refer to the "readme.txt" on the provided CD-ROM about camer-
as supporting the VMD search function. Refer to the operating instructions of the camera in use for further
information.
Motion detection search and playback (VMD search)
