Step 1
Insert an SD memory card into the recorder.
( Page 9)
Step 2
Click the [Copy] button on the operation panel of the
main monitor.
The copy panel will be displayed (if in playback
mode, playback will be paused).
Copy recorded images
It is possible to manually copy images recorded in the recorder onto an SD memory card.
It is recommended to make back-up copies on a regular basis for unexpected situations such as malfunction of
the hard disk drives.
It is impossible to copy recorded images when the recorder is in the following statuses.
• Whenthecopywindowisbeingopenedbyotheruservia a network
• WhentheSDmemorycardisbeingselectedbyanotheruservia a network
• Whenthesetupmenuisbeingdisplayed
• Whenthemediaotherthanharddiskdrivesisselected
The copied recorded images can be played on the recorder or on a PC using the dedicated viewer software.
The viewer software will be automatically copied to an SD memory card on which recorded images are copied.
Refer to page 83 for how to operate the viewer software.
Refer to page 35 for how to play the copied recorded images on the recorder.
Note:
• Pausetheplaybackbeforestartingcopyingwhenplayingrecordedimagesontherecorder.
• TocopyrecordedimagesontoanSDmemorycard,it is necessary to format the SD memory card in
advance. Refer to page 42 for how to format an SD memory card.
• Requiredtimeforcopyingvariesdependingonthedatasizetobecopied.Itwilltakelongertimetocopy
recorded images when they were recorded with a larger image capture size, in a higher quality or at a higher
recording rate even though the same number of cameras and the same duration are set for copying.
• Copyingofrecordedimagesmaysometimesbeperformedincorrectlywhenthereexist2ormoreimages
recorded at the same time and date resulting in change of the time and date setting or the auto time adjust-
ment function.
• Inthefollowingcases,thecopyingcurrentlybeingperformedwillstop.
• Whenanyofthesettingsoftherecorderischanged
• Whenauserwhostartedmanualcopyloggedout(Itwilltakearound90secondsuntilcopyingis
stopped after the web browser is closed.)
• Whentheoriginaldata(sourceforcopying)islost(overwrittenormalfunctionoftheharddiskdrive)
