Panasonic WJ-NV200K [22/97] Change the camera display position on the screen

Change the camera display position on the screen

The default camera display positions are as follows:

It is possible to change the camera image by dragging & dropping the number of the camera assigned to the

screen segment (1 to 16) onto the desired display position.

Note:

 • Whenacameraisassignedtoascreensegmenttowhichanothercameraisalreadyassigned,theimageof

the camera originally assigned to that position will disappear.

 • Theassignedcamerapositionisretainedeveniftherecorderisrebooted (note however that initializing the

settings will also reset the camera positions to the defaults).

 • Theaudioofthecameraassignedtothetopleftpositionwillbeoutput.

 • Audiooutputmaybedelayeddependingonthesizeofthedisplayedimage.

 • If"Mute"wasselectedonthecontrol screen, no audio will be output.

Display or hide the camera title

It is possible to display/hide the camera title displayed on the monitor.

3-screen 9-screen 9-screen 16-screen

1 2 3

4 5 6

1 2 3

4 5

6 7

2 3 4

5 6 7

8 9 10

14 15 1611 12 13

8 9

Step 1

Each time the [OSD] button is clicked, the camera

title will be displayed/hidden.

Note:

 • Thesettingtodisplay/hidethecameratitlewillbe

retained until the power is turned off. Once the

power is turned off and on again, the camera title

will be displayed on system start.
