[Cam]

A camera used for recording will be displayed.

[Evt]

Event type will be displayed. (☞ Page 69)

[Audio]

Nothing will be displayed here.

Important:

 • DonotremovetheSDmemorycardduringplay-

back of copied data on the SD memory card. It

may damage data on the SD memory card.

Note:

 • WhencheckingalistafterinsertingtheotherSD

memory card, select "HDD" for "Disk/Medium" in

the [Search] box first and then select "SD". Refer

to page 81 for information on how to play copied

images.
