21
Cleaning and care
Only service and clean the appliance when it is switched off and
the mains power plug has been disconnected from the mains power
supply.
After wash cleaning
Please use a moist soft cloth to clean the appliance housing.
Do not use any aggressive cleaning agents or solvents.
Remove fresh water tank and empty.
Empty dirty water tank.
Clean anti-swash insert, dirty water tank and wet filter using
clear, possibly warm water.
Check motor protection filter for contamination and clean
under flowing water and renew, if necessary.
Keep float (13b) in the dirty water tank clean and fully functional
at all times. This float interrupts the suction operation when the
dirty water tank is full.
Dry up spray water in suction chamber with soft cloth.
Remove contamination on the intake connector and on the
inside of the housing cover.
The housing cover can be taken off the appliance
for easier cleaning.
To do this open the cover and swing down vertically. Press the
cover forwards until it slides out of the hinge. Afterwards swing
the cover upwards and out of the way.
Insert in the housing cover vertically and close it to fasten. The
cover automatically clicks into the hinge.
Fill the fresh water tank with clear water to service
the pump and valves and to make the appliance
ready for operation.
Put the spraying system into operation (operate
the lever on the shut-off valve) over a wash basin,
for example.
The appliance and accessory parts are to be thoroughly dried
after being used for cleaning.
Press the shut-off valve lever to make the system completely
pressureless.
After vacuuming
1. AQUA filter system
Open housing cover by lifting up the cover catch.
Remove dirty water tank.
Pull the AQUA filter (12) out of the dirty water tank by means of the
grip and pour the dirty water away (for example in the toilet).
Remove foam filter (12a). To do this pull the AQUA filter frame slightly
upwards and then fold it over to the side out of the way.
Now thoroughly rinse the AQUA filter, foam filter, wet
filter and the dirty water tank with clear water. Do not
use any cleaning agents.
It is essential to ensure that the parts are dry before
using again.
The filter can be also removed for easier cleaning when dirt and
fluff have blocked the suction filter (12b); refit the suction filter after
cleaning.
Remove contamination and fluff on the suction connector.
2. HEPA filter
Your TWIN T2 PARQUET is provided with a high quality HEPA filter
(14), which can be cleaned several times depending on your needs
and the type of dust found in your home.
Clean your appliance as when needed (at the latest every six months)
and when the suction power decreases.
Remove the HEPA filter from the appliance and knock out the
dirt on a firm surface.
If the filter is strongly contaminated it can also be rinsed out
with clear water (without cleaning agent) and be subsequently
cleaned by knocking out the dirt.
Do not use any brushes for cleaning. Always
allow the filter to dry thoroughly before fitting it
back into the appliance again.
Do not damage the filter fins when cleaning the HEPA
filter.
The filter is to be replaced by a new filter should the suction power of
the appliance not be improved to a considerably extent after cleaning
the HEPA filter.
3. MKA microfilter
The MKA microfilter (19) is to be replaced every six months.
To do this press down the two plastic lugs on the blow-out cover and
fold it back.
Replace the MKA microfilter. Close the blow-out cover again.
Further supplies / special accessories
An extensive range of special accessories and further supplies are
available for your THOMAS TWIN T2 PARQUET dealer.
Get further details by returning the accompanying reply card to us or
get further information from your specialist dealer or directly from the
THOMAS Works Customer Service Department.
Note!
You can only assure a properly functioning appliance and efficient
cleaning by using original THOMAS accessories.
Customer service
Ask your dealer to tell you the THOMAS Customer
Service Area Centre responsible for you.
At the same time please tell your dealer the details
given on the rating plate of the THOMAS TWIN T2
PARQUET:
Repairs more especially to electrical parts are only
carried out by a qualified electrician. This, in turn,
ensures that your appliance remains fully functional
and safe in operation.
As a consequence, in the case of irregularities you
should get in touch with your specialist dealer or contact
the Works Customer Service Department directly.
Tel. <0049>(0)2735/788-581 or 582
Fax: <0049>(0)2735/788-599
