4 Connecting the TP-145, TP-146

Always switch off the power to each device before connecting it to your

TP-145, TP-146. After connecting your TP-145, TP-146, connect its

power and then switch on the power to each device.

You can use the TP-145 UXGA/Audio/Data Line Transmitter and the TP-146

UXGA/Audio/Data Line Receiver to configure a TP transmitter and receiver system

that transmit video, audio, and RS-232 control signals via TP cable.

To connect the TP-145 and the TP-146 to create a TP transmitter and receiver

system, as illustrated in Figure 4:

1. On the TP-145, connect:

 A UXGA source (for example, the graphics card on a laptop) to the

UXGA IN 15-pin HD (F) connector

 An audio source to the AUDIO IN 3.5mm mini connector, for example,

using a Kramer C-GMA/GMA cable (VGA 15-pin HD (M) +Audio jack to

VGA 15-pin HD (M) +Audio jack)

Not supplied. The full list of Kramer cables is available from

http://www.kramerelectronics.com. Alternatively, you can connect a UXGA

source to the UXGA IN 15-pin HD (F) connector, and a separate audio source to

the AUDIO IN 3.5mm mini connector

 An RS-232 cable with a 9-pin D-sub connector at one end to the

laptop, and a 3-pin terminal block connector at the other end to the

TP-145 RS-232 port (as defined in Section 4.1)

2. On the TP-146, connect:

 The UXGA OUT 15-pin HD (F) connector to the AV display system

 The S/PDIF AUDIO OUT RCA connector to a digital AV Receiver

 An RS-232 cable with a 3 pin terminal block connector at one end to

the TP-146 RS-232 port, and a 9-pin D-SUB connector at the other end

to the RS-232 port on the AV display system

3. Using STP cabling, connect the LINE OUT RJ-45 connector on the TP-145

to the LINE IN RJ-45 connector on the TP-146.

For details of how to wire a TP RJ-45 connector, see Section 4.2
