14
TP-145, TP-146 - Technical Specifications
6 Technical Specifications
TP-145
TP-146
INPUTS:
1 XGA on a 15-pin HD
connector,
1 unbalanced stereo
audio a 3.5mm mini
connector
1 twisted pair on an RJ-45
connector
OUTPUTS:
1 twisted pair on an
RJ-45 connector
1 UXGA on a 15-pin HD
connector,
1 S/PDIF on an RCA
connector,
1 unbalanced stereo
audio a 3.5mm mini
connector
PORTS:
1 RS-232 bidirectional terminal block
RESOLUTION:
Up to WUXGA, 1080p
MAX. OUTPUT LEVEL:
Video: 1.6V
Audio: 2.3V
CONTROLS:
EDID capture button
Level: –7.5dB to +4.4dB,
EQ.: 0dB to +33dBm
(130m) @ 50MHz
RS-232 BAUD RATE:
Up to 19200kbps
RS-232 MODE:
Full-duplex
BANDWIDTH:
Audio: 20Hz – 20kHz @0.5dB
S/N RATIO:
Audio: <–80dB
TOTAL GAIN:
Analog/analog: 0dB
Analog/SPDIF: –12dBFS
COUPLING:
AC
TND+N:
Audio: <0.01%
POWER CONSUMPTION:
12V DC 215mA
12V DC 550mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12.0cm x 7.8cm x 2.5cm (4.7" x 3.1" x 1.0") W, D, H
WEIGHT:
0.18kg. (0.4lbs.) approx.
INCLUDED ACCESSORIES:
Power supply
OPTIONAL:
RK-3T 19” rack adapter
Specifications are subject to change without notice at http://www.kramerelectronics.com
