TP-145, TP-146 - Acquiring the EDID
13
5 Acquiring the EDID
The TP-145 transmitter can capture the EDID information from a display device.
To load the default EDID:
1. Plug the 12V DC power adapter into the power socket on the TP-145 and
connect the adapter to the mains electricity.
2. With no display device connected to the TP-145, press the EDID CAPTURE
button.
3. The EDID STATUS LED flashes rapidly several times and the new EDID is
copied.
To capture the EDID information from a display device:
1. Using a short cable (for example, Kramer model number C-MGM/MGM-1),
connect the XGA INPUT 15-pin HD connector on the TP-145 to the input
XGA connector of the display.
2. Connect power to the display and switch it on.
3. Plug the 12V DC power adapter into the power socket on the TP-145 and to
the mains electricity.
4. Press the EDID CAPTURE button.
5. The EDID STATUS LED flashes slowly several times and the EDID is
captured.
6. Disconnect the display.
