Kramer VP-771 [105/129] Save or upload a configuration

VP-771 - Using the Embedded Web Pages

9.11 Save or Upload a Configuration

The VP-771 Web page lets you upload a saved configuration or save a

configuration. To do so, click the Upload (see Figure 94) and Save (see Figure 95)

buttons, respectively, which are located at the lower part of the menu list.

Note that the configuration is automatically saved to the Downloads

folder and uploaded from it as well

When saving a configuration, the file automatically saves it to the Downloads

Figure 94: Loading a Configuration

Figure 95: Saving a Configuration
