Feature
Function
30
VIDEO INPUT
Connectors
HDMI
Connect to the HDMI source (from 1 to 2)
31
PC 15-pin HD
Connect to the computer graphics source (from 1 to 2)
32
Y RCA
Connect all three connectors to the component video source
33
Pb RCA
34
Pr RCA
35
CV RCA
Connect to the composite video source (from 1 to 2)
36
DISPLAYPORT
Connect to the DisplayPort source
37
SDI IN
Connect to the SDI source
38
SDI LOOP
Connect to a local display
39
VIDEO
OUTPUT
Connectors
PC 15-pin HD
Connect to a computer graphics acceptor
40
SDI BNC
Connect to an SDI acceptor
41
HDMI
Connect to an HDMI acceptor
42
DGKAT RJ-45
Connect to a DGKat receiver (for example, Kramer PT-572+)
43
RS-232 9-pin D-sub Port
Connect to the PC or other serial controller
44
ETHERNET Connector
Connects to the PC or other Controller through computer networking
45
REMOTE Terminal Block Connectors
For remotely switching the inputs and PIP input via contact closure switches
46
Power Connector with Fuse
AC connector, enabling power supply to the unit
47
POWER Switch
Switch for turning the unit ON or OFF
10
VP-771 – Overview
