Kramer VP-771 [110/129] Default communication parameters
![Kramer VP-771 [110/129] Default communication parameters](/views2/1153532/page110/bg6e.png)
102
VP-771 - Technical Specifications
12.1 Default Communication Parameters
RS-232
Protocol
3000 (Default)
Legacy
Baud Rate:
115,200
9,600
Data Bits:
8
8
Stop Bits:
1
1
Parity:
None
None
Command Format:
ASCII
ASCII
Example (Set display mode to Picture in Picture):
#Y 0,110,1<CR>
>Y 0 110 1<CR>
Ethernet
To reset the IP settings to the factory reset values, power cycle the device while holding in the
Ethernet Reset button, located on the rear panel of the unit
IP Address:
192.168.1.39
Subnet mask:
255.255.000.000
Default gateway:
000.000.000.000
TCP Port #:
5000
UDP Port #:
50000
Maximum UDP Ports:
10
Maximum TCP Ports:
4
Web page password
1234
Full Factory Reset
Front panel buttons
Turn power off. Turn power on again while holding the RESET TO
XGA/720p front panel button. The LEDs blink. Full factory reset is
complete once the LEDs cease to blink and react normally
Note that full factory reset includes Ethernet reset as well.
OSD
Factory Reset through the Misc menu item
Web pages
Factory reset via the Device Settings embedded Web page
Protocol 3000
Use “Factory” command or #Y 0,771,1<CR>
12.2 Input Resolutions
This section defines the input resolutions for each input
12.2.1 SDI Input Resolutions
SDI Input Resolution
NTSC
720_P60
1080_P24
1080_P50
PAL
1080_I50
1080_P25
1080_P60
720_P50
1080_I60
1080_P30
