28
underbolt AIC
Connector
(5-pin TB1)
(see p.7, No. 25)
Please connect a underbolt™
add-in card (AIC) to this
connector via the GPIO cable.
Serial Port Header
(9-pin COM1)
(see p.7, No. 27)
is COM1 header
supports a serial port
module.
TPM Header
(17-pin TPMS1)
(see p.7, No. 26)
is connector supports Trusted
Platform Module (TPM) system,
which can securely store keys,
digital certicates, passwords,
and data. A TPM system also
helps enhance network security,
protects digital identities, and
ensures platform integrity.
CCTS#1
RRTS#1
DDSR#1
DDTR#1
RRXD1
GND
TTXD1
DDCD#1
1
RRI#1
1
GN D
SM B_DA TA_M AIN
LA D2
LA D1
GN D
S_ PWRD WN #
SE RIRQ #
GN
D
P CICLK
P CIRST
#
LA D3
+3 V
LA D0
+3V S B
GN D
FR AM E
SM B_CL K_MA IN
