ASRock fatal1ty z170 gaming k6+ [37/113] Smart switches
![ASRock fatal1ty z170 gaming k6+ [37/113] Smart switches](/views2/1159552/page37/bg25.png)
English
29
Fatal1ty Z170 Gaming K6+ Series / Fatal1ty Z170 Gaming K6 Series
2.7 Smart Switches
e motherboard has three smart switches: Power Switch, Reset Switch and Clear
CMOS Switch, allowing users to quickly turn on/o the system, reset the system or
clear the CMOS values.
Power Switch
(PWRBTN)
(see p.7, No. 7)
Power Switch allows users
to quickly turn on/o the
system.
Reset Switch
(RSTBTN)
(see p.7, No. 6)
Reset Switch allows
users to quickly reset the
system.
Clear CMOS Switch
(CLRCBTN)
(see p.9, No. 16)
Clear CMOS Switch
allows users to quickly
clear the CMOS values.
is function is workable only when you power o your computer and unplug the power
supply.
Power
Reset
