ASUS Z170I PRO GAMING
1-3
1.2.4 Layout contents
1.3 Central Processing Unit (CPU)
ThismotherboardcomeswithasurfacemountLGA1151socketdesignedforthe6th
Generation Intel
®
Core™i7/Core™i5/Core™i3,Pentium
®
,andCeleron
®
processors.
Connectors/Jumpers/Slots/LED Page
1.
CPU,chassisfanconnectors(4-pinCPU_FAN,4-pinCHA_FAN1~2)
1-16
2.
ATXpowerconnectors(24-pinEATXPWR,8-pinATX12V)
1-17
3.
Intel
®
LGA1151CPUsocket
1-3
4. QLEDs(BOOT_DEVICE_LED,VGA_LED,DRAM_LED,CPU_LED) 1-22
5. DDR4DIMMslots 1-7
6. Systempanelconnector(10-1pinF_PANEL) 1-20
7. Intel
®
Z170SerialATA6.0Gb/sconnector(7-pinSATA6G_1~4,
SATAEXPRESS)
1-19
8. USB3.0connector(20-1pinUSB3_12) 1-18
9. USB2.0connector(10-1pinUSB1112) 1-18
10. Speakerconnector(4-pinSPEAKER) 1-19
11. ClearRTCRAM(2-pinCLRTC)header 1-12
12. StandbyPowerLED(SB_PWR) 1-22
13. M.2Socket3 1-21
14. TPMconnector(14-1pinTPM) 1-15
15. SupremeFXLEDLighting 1-23
16. Frontpanelaudioconnector(10-1pinAAFP) 1-16
17. RTCbatteryheader(2-pinBATT_CON) 1-12
18. Digitalaudioconnector(4-1pinSPDIF_OUT) 1-15
Z170I PRO GAMING CPU socket LGA1151
