ASUS Z170I PRO GAMING
1-7
1.4 System memory
1.4.1 Overview
ThismotherboardcomeswithtwoDoubleDataRate4(DDR4)DualInlineMemoryModule
(DIMM)sockets.ADDR4moduleisnotcheddifferentlyfromaDDR,DDR2,orDDR3module.
DONOTinstallaDDR,DDR2,orDDR3memorymoduletotheDDR4slot.
AccordingtoIntel
®
CPUspec,DIMMvoltagebelow1.2Visrecommendedtoprotectthe
CPU.
1.4.2 Memory configurations
Youmayinstall2GB,4GB,8GB,and16GBunbufferednon-ECCDDR4DIMMsintothe
DIMMsockets.Youcanrefertotherecommendedmemorypopulationbelow.
Recommended memory configurations
Z170I PRO GAMING 288-pin DDR4 DIMM sockets
DIMM_B1
DIMM_A1
