ASUS Z170I PRO GAMING
1-21
11. M.2 socket 3
ThissocketallowsyoutoinstallanM.2(NGFF)SSDmodule.
• ThissocketsupportsMKeyand2242/2260/2280storagedevices.
• Fora2242storagedevice,usethebundled2242mountingkit.
• Beforeinstallinga2242M.2SSDmodule,ensurethatthemountingkitisproperly
installedwiththebiggerscrewholeonthe2260standoff.
• WhenusingIntel
®
DesktopResponsivenesstechnologieswithPCIeM.2device,
ensure to set up the Windows
®
UEFIoperatingsystemunderRAIDmode.
TheM.2(NGFF)SSDmoduleispurchasedseparately
Z170I PRO GAMING M.2 (SOCKET3)
M.2(SOCKET3)
2
3
1
To install a 2242 M.2 SSD module:
1. Alignthebiggerholeonthemountingkitwiththe2260
standoff and secure it with a screw.
2. Installthe2242M.2SSDmoduletotheM.2socket.
3. SecuretheM.2SSDmoduletotheM.2socketwitha
screw.
