ASUS Z170I PRO GAMING

2‑23

The following items appear only when you set the Turbo Mode to [Enabled].

Turbo Mode Parameters

Long Duration Package Power Limit [Auto]

Allows you to limit the Turbo Ratio’s time duration that exceeds the TDP (Thermal

Design Power) for maximum performance. Use the <+> or <‑> keys to adjust the value.

The values range from 1 W to 4096 W.

Package Power Time Window [Auto]

Also known as Power Limit 1, this item allows you to maintain the time window for

Turbo Ratio over TDP (Thermal Design Power). Use the <+> or <‑> keys to adjust the

value. The values range from 1 to 127 in seconds.

Short Duration Package Power Limit [Auto]

Also known as Power Limit 2, this item allows you to provide rapid protection when

the package power exceeds the Power Limit 1. Use the <+> or <‑> keys to adjust the

value. The values range from 1 W to 4096 W.

IA AC Load Line [Auto]

This item allows you to set the AC loadline dened in 1/100 mOhms. Use the <+> and <‑>

keys to adjust the value. Conguration options: [Auto] [0.01] ‑ [62.49]

IA DC Load Line [Auto]

This item allows you to set the DC loadline dened in 1/100 mOhms. Use the <+> and <‑>

keys to adjust the value. Conguration options: [Auto] [0.01] ‑ [62.49]

2.5.13 CPU Core/Cache Current Limit Max. [Auto]

Allows you to set a higher current limit to prevent a frequency or power throttling when

overclocking. Use the <+> or <‑> keys to adjust the value. The values range from 0.00A to

255.50A with a 0.25A interval.

2.5.14 Min. CPU Cache Ratio [Auto]

Allows you to set the minimum possible CPU cache ratio. Use the <+> or <‑> keys to adjust

the value. The values range from 0 to 83 with a 1 interval.

2.5.15 Max. CPU Cache Ratio [Auto]

Allows you to set the maximum possible CPU cache ratio. Use the <+> or <‑> keys to adjust

the value. The values range from 8 to 83 with a 1 interval.

2.5.16 Internal PLL Voltage [Auto]

Allows you to congure the offset for the Core PLL VCC Trim.
