ASUS Z170I PRO GAMING
1-19
8. Intel
®
Z170 Serial ATA 6.0Gb/s connector (7-pin SATA6G_1~6, SATAEXPRESS)
ThisconnectorconnectstoSerialATA6.0Gb/sharddiskdrivesviaSerialATA6.0
Gb/s signal cables.
IfyouinstalledSerialATAharddiskdrives,youcancreateaRAID0,1,5,and10
congurationwiththeIntel
®
RapidStorageTechnologythroughtheonboardIntel
®
Z170chipset.
• Theseconnectorsaresetto[AHCI]bydefault.IfyouintendtocreateaSerialATA
RAIDsetusingtheseconnectors,settheSATAModeitemintheBIOSto[RAID].
Refertosection2.6.3 PCH Storage Configuration for details.
• BeforecreatingaRAIDset,refertothemanualbundledinthemotherboardsupport
DVD.
TheSATAEXPRESSconnectorcansupportoneSATAExpressdeviceortwoSATA
devices.
9. Speaker connector (4-pin SPEAKER)
The4-pinconnectorisforthechassis-mountedsystemwarningspeaker.Thespeaker
allows you hear system beeps and warnings.
A
B
A B
SATA6G_4
SATA6G_2
SATA6G_1
GND
RSATA_TXP4
RSATA_TXN4
GND
RSATA_RXN4
RSATA_RXP4
GND
SATA6G_3
GND
RSATA_TXP3
RSATA_TXN3
GND
RSATA_RXN3
RSATA_RXP3
GND
Z170I PRO GAMING Intel
®
SATA 6.0Gb/s connectors
SATAEXPRESS
GND
RSATA_TXP1
RSATA_TXN1
GND
RSATA_RXN1
RSATA_RXP1
GND
GND
RSATA_TXP2
RSATA_TXN2
GND
RSATA_RXN2
RSATA_RXP2
GND
Floating
Device_Reset
GND
Detection
Speaker Out
GND
GND
+5V
SPEAKER
PIN 1
Z170I PRO GAMING Speaker Out connector
