ASUS TROOPER B150 D3
1-7
1.3.2 CPU heatsink and fan assembly installation
To install the CPU heatsink and fan assembly
2
A
A
B
B
1
ApplytheThermalInterfaceMaterialtothe
CPUheatsinkandCPUbeforeyouinstall
the heatsink and fan if necessary.
3 4
