viii
TROOPER B150 D3 specifications summary
Specications are subject to change without notice.
Internal I/O
connectors
1 x USB 3.0/2.0 connector supports additional 2 USB 3.0/2.0 ports (19-pin;
beige)
1 x USB 2.0/1.1 connectors support additional 2 USB 2.0/1.1 ports (black)
6 x SATA 6Gb/s connectors (black)
1 x CPU fan connector (4-pin beige) for both 4-pin (PWM mode) and 3-pin
(DC mode) CPU coolers control
2 x Chassis fan connectors (4-pin Black)
Front panel audio connector (AAFP)
24-pin EATX Power connector
8-pin EATX 12V Power connector
1 x S/PDIF Out header
1 x TPM header
1 x Clear CMOS jumper
1 x COM port
1 x Chassis intrusion jumper
BIOS features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0,
ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS
3, My Favorites, Quick Note, Last Modied log, F12 PrintScreen, and ASUS
DRAM SPD (Serial Presence Detect) memory information
Manageability
WfM 2.0, DMI 3.0, WOL by PME, PXE
Support DVD
Drivers
ASUS utilities
ASUS/TUF CPU-Z
Anti-virus software (OEM version)
Operating system
support
Windows
®
10 (64-bit)
Windows
®
8.1 (64-bit)
Windows
®
7 (64-bit/32-bit)
Form factor
ATX Form Factor, 12” x 7.8” (30.5cm x 19.8cm)
