1-10
Chapter 1: Product Introduction
Trooper B150 D3 Motherboard Qualified Vendors Lists (QVL)
Vendors Part No. Size SS/DS Chip
Brand
Chip NO. Timing Voltage DIMM
socket
support
(Optional)
1 2
CORSAIR CMD16GX3M2A1866C9
(Ver5.29)(XMP)
16GB(2x8GB) DS - - 18669-9-9-27 1.5 • •
CORSAIR CMD16GX3M4A1866C9
(Ver4.13)(XMP)
16GB(4x4GB) DS - - 9-10-9-27 1.5 • •
CORSAIR CMD16GX3M4A1866C9
(Ver8.16)(XMP)
16GB(4x4GB) DS - - 9-10-9-27 1.5 • •
CORSAIR CMD32GX3M4A1866C9
(Ver3.24)(XMP)
32GB(4x8GB) DS - - 9-10-9-27 1.5 • •
CORSAIR CMD8GX3M2A1866C9(Ver4.13)
(XMP)
8GB(2x4GB) DS - - - 1.5 • •
CORSAIR CMD8GX3M2A1866C9(Ver5.12)
(XMP)
8GB(2x4GB) DS - - 9-10-9-27 1.5 • •
CORSAIR CMD8GX3M2A1866C9(Ver8.16)
(XMP)
8GB(2x4GB) DS - - 9-10-9-27 1.5 • •
CORSAIR CMY16GX3M2A1866C9(Ver
4.21)(XMP)
16GB(2x8GB) DS - - 9-10-9-27 1.5 • •
CORSAIR CMY8GX3M2A1866C9(Ver3.24)
(XMP)
8GB(2x4GB) DS - - 9-10-9-27 1.5 • •
CORSAIR CMY8GX3M2C1866C10
(Ver4.19)(XMP)
8GB(2x4GB) DS - - 10-11-10-30 1.35 • •
CORSAIR CMZ16GX3M2A1866C10
(Ver5.29)(XMP)
16GB(2x8GB) DS - - 10-11-10-30 1.5 • •
CORSAIR CMZ16GX3M2A1866C9(XMP) 16GB(2x8GB) DS - - 1866-9-10-9-27 1.5 • •
CORSAIR CMZ32GX3M4X1866C10
(Ver3.23)(XMP)
32GB(4x8GB) DS - - 10-11-10-27 1.5 •
CORSAIR CMZ8GX3M2A1866C9(Ver8.16)
(XMP)
8GB(2x4GB) DS - - 9-10-9-27 1.5 • •
CORSAIR CMZ8GX3M2A1866C9G
(Ver5.12)(XMP)
8GB(2x4GB) DS - - 18669-10-9-27 1.5 • •
crucial BLE4G3D1869DE1TX0.16FKR
(XMP)
4GB DS - - 9-9-9-27 1.5 • •
crucial BLE8G3D1869DE1TX0.16FED
(XMP)
16GB(2x8GB) DS - - 1866-9-9-9-27 1.5 • •
crucial BLS8G3D18ADS3.16FED 8GB DS - - 10-10-10-30 1.5 • •
crucial BLT8G3D1869DT1TX0.16FED
(XMP)
8GB DS - - 9-9-9-27 1.5 • •
G.SKILL F3-14900CL10Q-32GBZL(XMP) 32GB(4x8GB) DS - - 10-11-10-30 1.5 • •
G.SKILL F3-14900CL9Q-16GBZL(XMP) 16GB(4x4GB) DS - - 9-10-9-28 1.5 • •
G.SKILL F3-1866C10Q2-64GZM(XMP) 64GB(2x8GB) DS - - 10-11-10-30 1.5 • •
G.SKILL F3-1866C10Q2-64GZM(XMP) 64GB(2x8GB) DS - - 10-11-10-30 1.5 • •
G.SKILL F3-1866C9Q-32GXM(XMP) 32GB(4x8GB) DS - - 9-10-9-28 1.5 • •
GeIL GEEL316GB1866C9DC(XMP) 16GB(2x8GB) DS - - 1866-9-10-9-28 1.65 • •
Kingston HX318C10FWK2/16 16GB(2x8GB) DS - - 10-11-10-30 1.5 • •
Kingston KHX1866C9D3K2/8GX(XMP) 8GB(2x4GB) DS - - - 1.65 • •
Kingston KHX18C10AT3K8/64X(XMP) 64GB(8x8GB) DS - - 10-11-10-30 1.5 • •
panram PUD31866C94GPSB(XMP) 4GB SS - - 11-11-11-28 1.65 • •
Silicon
Power
SP004GXLYU186NSA(XMP) 4GB SS - - 1866-9-11-9-27 - • •
Silicon
Power
SP008GXLYU186NSA(XMP) 8GB DS - - 1866-9-11-9-27 - • •
Team TED38GM1866C13BK 8GB DS Hynix H5TQ4G83AFR 13-13-13-32 1.5 • •
V-color TD4G16C13-RD 4GB DS - - 1866-13-13-
13-32
1.5 • •
DDR3 1866 (O.C.) MHz capability
