ASUS TROOPER B150 D3
1-13
Silicon
Power
SP008GXLYU160NSA(XMP) 8GB DS - - 1600-9-9-
9-27
- • •
SKHynix HMT41GU6AFR8A-PB 8GB DS SKhynix H5TC4G83AFR 1600-11-11-
11-28-1
- • •
SKHynix HMT41GU6BFR8A-PB 8GB DS SKHynix H5TC4G83BFRPBA 11-11-11-28 - • •
SKHynix HMT451U6AFR8A-PB 4GB SS SKhynix H5TC4G83AFR 1600-11-11-
11-28-1
- • •
SKHynix HMT451U6AFR8A-PB 4GB SS SKhynix H5TC4G83AFR 1600-11-11-
11-28-1
- • •
SKHynix HMT451U6BFR8A-PB 4GB SS SKHynix H5TC4G83BFRPBA 11-11-11-28 - • •
Team TED34G1600C11BK 4GB SS Team T3D5128HT-16 11-11-11-28 1.5 • •
Team TED38G1600C11BK 8GB SS Team T3D10248HT-16D4 11-11-11-28 1.5 • •
Team TLD38G1600HC9BK(XMP) 8GB DS - - 9-9-9-24 1.5 • •
UMAX 84E44G93UM-16BPSYW 4GB SS UMAX U2S96D30TP-16 1600-11-11-
11-28
- • •
UMAX 84E48G93UM-16BPSYW 8GB DS UMAX U2S96D30TP-16 1600-11-11-
11-28
- • •
V-color TD4G8C11-H11 4GB SS SKhynix H5TQ4G83AFR 11-11-11-28 - • •
DDR3 1600 MHz capability
Vendors Part No. Size SS/DS Chip
Brand
Chip NO. Timing Voltage DIMM
socket
support
(Optional)
1 2
AMD AE32G1339U1-U 2GB SS AMD 23EY4587MB3H - 1.5 • •
AMD AE34G1339U2-U 4GB DS AMD 23EY4587MB3H - 1.5 • •
ASint SLA302G08-EDJ1C 2GB SS ASint 302G08-DJ1C - - • •
ASint SLA304G08-EDJ1B 4GB SS Asint 304G08-DJ1B 9-10-10-26 - • •
ASint SLA304G08-EDJ6A 4GB SS ASint 304G08-DJ6A 1333-9-9-9-24 1.5 • •
ASint SLA304G08-EDJ6B 4GB SS ASint 304G08-DJ6B 1333-9-9-9-24 1.5 • •
ASint SLB304G08-EDJ1B 8GB DS Asint 304G08-DJ1B 9-9-9-24 - • •
CORSAIR CMV8GX3M1A1333C9 8GB DS - - 9-9-9-24 - • •
CORSAIR CMV8GX3M2A1333C9 8GB(2x4GB) DS - N/A 9-9-9-24 - • •
CORSAIR CMX4GX3M1A1333C9
(Ver2.12)
4GB(1x4GB) DS - - 9-9-9-24 1.5 • •
CORSAIR CMX4GX3M1A1333C9
(Ver5.11)
4GB(1x4GB) DS - - 9-9-9-24 1.5 • •
innodisk M3UN-2GHJBC09 2GB SS Hynix H5TQ2G83CFRH9C 9-9-9-24 - • •
innodisk M3UN-4GHJAC09 4GB DS Hynix H5TQ2G83CFRH9C 9-9-9-24 - • •
Kingston KVR1333D3N9H/4G 4GB DS ELPIDA J2108BDBG-GN-F - 1.5 • •
Kingston KVR13N9S8H/4 4GB SS ELPIDA J4208BBBG-GN-F - 1.5 • •
MACH
XTREME
MXD3U133316GQ 16GB(4x
4GB)
DS - - - - • •
MACH
XTREME
MXD3V13332GS 2GB SS Mach
Xtreme
C2S46D30-D313 - - • •
Silicon
Power
SP002GBLTU133V02 2GB SS S-POWER 20YT3NG 9-9-9-24 - •
Silicon
Power
SP004GBLTU133V02 4GB DS S-POWER 20YT3NG 9-9-9-24 - • •
UMAX 84E44G93UM-13BPSYW 4GB SS UMAX U2S96D30TP-13 1333-9-9-9-24 - • •
UMAX 84E48G93UM-13BPSYW 8GB DS UMAX U2S96D30TP-13 1333-9-9-9-24 - • •
DDR3 1333 MHz capability
Vendors Part No. Size SS/DS Chip
Brand
Chip NO. Timing Voltage DIMM
socket
support
(Optional)
1 2
