vi
(continued on the next page)
TROOPER B150 D3 specifications summary
CPU
LGA1151 socket for 6th Generation Intel
®
Core™ i7/ i5/ i3/Pentium
®
/
Celeron
®
Processors
Supports 14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
*
Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for CPU support list.
Chipset
Intel
®
B150 Express Chipset
Memory
2 x DIMM, max. 32GB, DDR3 1600/1333 MHz, non-ECC, un-buffered
memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* To prevent system instability, either install DDR3L DIMMs or DDR3 DIMMs with
voltage lower than 1.5V.
** Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List).
VGA Integrated Graphics Processor - Intel
®
HD Graphics support
Multi-VGA output support: DVI/D-sub port
- Supports DVI with max. resolution 1920 x 1200@60Hz
- Supports D-sub with max. resolution 1920 x 1200@60Hz
Supports Intel
®
InTru™ 3D/Quick Sync Video/Clear Video HD Technology/
Insider™
* Maximum shared memory of 512MB
Multi-GPU support Supports AMD
®
Quad-GPU CrossFireX™ Technology
Expansion slots
1 x PCI Express 3.0/2.0 x16 slot
1 x PCI Express 3.0/2.0 x16 slot [black] (max. at x1 mode)
1 x PCI Express 3.0/2.0 x16 slot [black] (max. at x4 mode, compatible with
x1, x2 and x4 devices)
2 x PCI Express 3.0/2.0 x1 slots
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS TROOPER B150 D3 motherboard
Cables
2 x Serial ATA 6.0 Gb/s cables
Accessories
1 x I/O Shield
1 x TUF inside sticker
Application DVD
Support DVD
Documentation
User manual
TUF Certication card
TUF 5-Year Warranty card (by region)
If any of the above items is damaged or missing, contact your retailer.
