vii
TROOPER B150 D3 specifications summary
Storage
Intel
®
B150 Express Chipset with Intel Rapid Storage
Technology 14 Support:
- 6 x SATA 6Gb/s ports (black)
LAN
Realtek
®
8111H Gigabit LAN controller
Audio
Realtek
®
ALC887 8-Channel High Denition Audio CODEC
- Supports Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- Separate layer for left and right track, ensuring both sound deliver equal
quality
- LED-lit Audio Shielding: Ensures precision analog/digital separation and
greatly reduced multi-lateral interference, with a gorgeous illuminated
trace path
USB
Intel
®
B150 Express Chipset - supports ASUS USB 3.0 Boost
- 2 x USB 3.0/2.0 ports at mid-board for front panel support
- 4 x USB 3.0/2.0 ports at back panel (blue)
- 6 x USB 2.0/1.1 ports (2 ports at mid-board, 4 ports at the back panel)
Exclusive TUF
features
“Ultimate COOL!” Thermal Solution
- TUF Thermal Radar Core
“TUF ENGINE!” Power Design
- 3+2 Digital Phase Power Design
- TUF Components (TUF Cap, TUF Chokes & MOSFET; certied by
military-standard)
- ASUS DIGI + VRM
“Safe & Stable!” Guardian Angel
- TUF LANGuard
- TUF ESD Guards 2
Other special
features
- USB 3.0 Boost featuring speedy USB 3.0 transmission
- Ai Charger
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
- AI Suite 3
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS CrashFree BIOS 3
- EZ Update
- Disk Unlocker
- ASUS EZ Flash 3
- Multi-language BIOS
Back panel I/O
ports
1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
1 x DVI-D port
1 x D-Sub port
1 x LAN (RJ-45) port
4 x USB 3.0/2.0 ports (blue)
4 x USB 2.0/1.1 ports
8-channel audio output
(continued on the next page)
