Chapter 1: Product Introduction

1.2.4 Layout contents

Connectors/Jumpers/Slots/LED Page

1. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V)

1-20

2. Intel

LGA1151 CPU socket

1-5

3. CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN)

1-19

4. DDR4 DIMM slots

1-8

5. Intel

B150 Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1-6)

1-23

6. System panel connector (20-5 pin PANEL)

1-24

7. Standby Power LED (SB_PWR)

1-25

8. USB 3.0 connector (20-1 pin USB3_12)

1-18

9. USB 2.0 connector (10-1 pin USB1112)

1-17

10. TPM connector (14-1 pin TPM)

1-22

11. Clear RTC RAM jumper (2-pin CLRTC)

1-13

12. Serial port connector (10-1 pin COM)

1-16

13. Front panel audio connector (10-1 pin AAFP)

1-21

14. SupremeFX LED

1-26

15. M.2 Socket 3

1-16
