ASUS B150M PRO GAMING
2‑25
CPU Power Management Configuration
This item allows you to congure CPU power management.
Intel
®
SpeedStep
TM
[Auto]
This item allows the operating system to dynamically adjust the processor voltage and
cores frequency, resulting to a decreased average power consumption and decreased
average heat production.
Conguration options: [Auto] [Disabled] [Enabled]
Turbo Mode [Enabled]
This item allows you to enable your core processor’s speed to run faster than the
base operating frequency when it is below operating power, current and temperature
specication limit.
Conguration options: [Disabled] [Enabled]
CPU C states [Auto]
This item allows you to enable or disable CPU C states.
Conguration options: [Auto] [Disabled] [Enabled]
The following items appear only when you set the CPU C states to [Enabled].
Enhanced C-states [Enabled]
This item allows you to enable or disable C1E. When enabled, CPU will
switch to minimum speed when all cores enter C‑State.
Conguration options: [Disabled] [Enabled]
CPU C3 Report [Enabled]
This item allows you to enable or disable the CPU C3 report to the
operating system.
Conguration options: [Disabled] [Enabled]
CPU C6 Report [Enabled]
This item allows you to enable or disable the CPU C6 report to the
operating system.
Conguration options: [Disabled] [Enabled]
CPU C7 Report [CPU C7s]
This item allows you to enable or disable the CPU C7 report to the
operating system.
Conguration options: [Disabled] [CPU C7] [CPU C7s]
CPU C8 Report [Enabled]
This item allows you to enable or disable the CPU C8 report to the
operating system.
Conguration options: [Disabled] [Enabled]
Package C State limit [Auto]
This item allows you to set the Package C State limit.
Conguration options: [C0/C1] [C2] [C3] [C6] [C7] [C7s] [C8] [Auto]
CFG lock [Disabled]
This item allows you to enable or disable the CFG lock.
Conguration options: [Disabled] [Enabled]
