ASUS B150M PRO GAMING
2‑15
2.4.1 Language [English]
Allows you to choose the BIOS language version from the options.
Conguration options: [English] [Español]
[Русский] [Korean
]
2.4.2 Security
The Security menu items allow you to change the system security settings.
2.4 Main menu
The Main menu screen appears when you enter the Advanced Mode of the BIOS Setup
program. The Main menu provides you an overview of the basic system information, and
allows you to set the system date, time, language, and security settings.
• If you have forgotten your BIOS password, erase the CMOS Real Time Clock (RTC)
RAM to clear the BIOS password. See section 1.6 Jumpers for information on how to
erase the RTC RAM.
• The Administrator Password and User Password items on the screen show the
default Not Installed. After you set a password, these items show Installed.
