vii
B150M PRO GAMING specifications summary
(continued on the next page)
Audio
SupremeFX 8-Channel High Definition Audio CODEC*
- Supports Jack-detection and Front Panel MIC Jack-retasking
- High quality 115dB SNR stereo playback output
Audio Features:
- SupremeFX Shielding™ Technology
- Headphone AMP
* Use a chassis with HD audio module in the front panel to support an 8-channel audio output.
Storage
Intel
®
B150 Chipset
- 6 x SATA 6.0 Gb/s connectors
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support
(both SATA & PCIE 3.0 x 4 mode)*
* When the M.2 Socket 3 is operating in SATA mode, SATA port 1 will be disabled.
LAN
Intel
®
Gigabit LAN
Anti-surge LANGuard
USB
Intel
®
B150 Chipset - supports ASUS USB 3.0 Boost
- 6 x USB 3.0/2.0 ports (2 ports at mid-board; 4 ports at back panel, blue)
- 6 x USB 2.0/1.1 ports (2 ports at mid-board; 4 ports at back panel)
ASUS
gaming
features
Gamer’s Guardian
- DIGI+ VRM
- DRAM Overcurrent Protection
- ESD Guards on LAN, Audio, KB/MS and USB 3.0/2.0 ports
- Highly Durable Components
- Stainless Steel Back I/O
- Q-Design (Q-Shield, Q-DIMM, Q-Slot)
Performance Level Up
- DIGI+ VRM
- AI Suite 3
- Fan Xpert featuring Fan Auto Tuning function and multiple thermistors selection for
optimized system cooling control
- UEFI BIOS EZ Mode (CrashFree BIOS 3, EZ Flash 3)
ASUS Exclusive Features
- ASUS CPU-Z
- USB 3.0 Boost featuring speedy USB 3.0 transmission
- AI Charger
- Disk Unlocker
- Push Notice
- Media Streamer
